1. Part No. Expression:

S C I 1 0 0 8 L P - 3 N 3 K F

a) Series Code

d) Inductance Code

(a)

(b) (c)

(d) (e)(f)

b) Dimension Code

e) Tolerance Code

c) Type Code: LP (Low Profile) f) F: RoHS Compliant

2. Configuration & Dimensions :

Unit: mm

3. Schematic

A

B

C

D

E

F

G

H

I

J

2.92 Max. 2.79 Max. 1.40 Max. 0.65 Ref. 2.03 Ref. 0.51 Ref. 1.52 Ref. 2.54 Ref. 1.02 Ref. 1.27 Ref.
