17/10/2017 V2.0

1

Features:

> High brightness surface mount LED using thin film technology.

> 120° viewing angle.

> Small package outline (LxWxH) of 3.2 x 2.8 x 1.8mm.

> Qualified according to JEDEC moisture sensitivity Level 2.

> Compatible to both IR reflow soldering.

> Environmental friendly; RoHS compliance.

> Qualified based on AEC-Q101 Standard.

> Passed Corrosion Resistant Test.

DomiLED

Synonymous with function and performance, the DomiLED series is

perfectly suited for a variety of cross-industrial applications due to its

small package outline, durability and superior brightness.

DATA SHEET:

DomiLED

IR : DR8-NJS

© 2005 DomiLED is a trademark of DOMINANT Opto Technologies.

All rights reserved. Product specifications are subject to change without notice.

Applications:

> Automotive: Interior applications.

> Infrared illumination.

> Sensor technology.

> IR data transmission.

DOMINANT

Opto Technologies

Innovating Illumination

TM
