2SA2029-R datasheet(1/4 Pages) MCC

部件名	2SA2029-R

功能描述	PNPGeneral Purpose Transistors

PDF	4 Pages

Scroll/Zoom	100%

制造商	MCC [Micro Commercial Components]

网页	http://www.mccsemi.com

标志

1 / 4 page

PNP

General Purpose

Transistors

Features

•

Complement to 2S

C5658

Maximum Ratings @ 25OC Unless Otherwise Specified

Symbol

Rating

Unit

VCEO

Collector-Emitter Voltage

-50

V

VCBO

Collector-Base Voltage

-60

V

VEBO

Emitter-Base Voltage

-7

V

IC

Collector Current-Continuous

-150

mA

PC

Collector Dissipation

1

50

mW

TJ

Operating Junction Temperature

-55 to +150

TSTG

Storage Temperature

-55 to +150

Electrical Characteristics @ 25OC Unless Otherwise Specified

Symbol

Parameter

Min

Typ

Max

Units

V(BR)CEO

Collector-Emitter Breakdown Voltage

(IC=

-1mAdc, I

B=0)

-50

---

Vdc

V(BR)CBO

Collector-Base Breakdown Voltage

(IC=

-50µAdc, I

E=0)

-60

---

Vdc

V(BR)EBO

Collector-Emitter Breakdown Voltage

(IE=

-50µAdc, I

C=0)

-7

---

Vdc

ICBO

Collector Cutoff Current

(VCB=

-60Vdc, I

E=0Vdc)

---

-0.1

Adc

IEBO

Emitter Cutoff Current

(VEB=

-6Vdc, I

C=0Vdc)

---

-0.1

Adc

hFE

DC Current Gain

(IC=

-1mAdc, V

CE=

-6Vdc)

120

---

560

---

VCE(sat)

Collector-Emitter Saturation Voltage

(IC=

-50mAdc, I

B=

-5mAdc)

---

-0.5

Vdc

fT

Transition Frequency

(VCE=

-12Vdc, I

C=2mAdc, f=100MHz)

---

1

40

---

MHz

Cob

Output Capacitance

(VCB=

-12Vdc, f=1.0MHz, I

E=0)

---

5.0

pF

Classification OF hFE

Rank

Q

R

S

Range

120-270

180-390

270-560

Marking

FQ

FR

FS

SOT-

723

omponents

20736 Marilla

Street Chatsworth

!"#

$% !"#

Revision: A

2016/02/18

www.mccsemi.com

1 of

4

2S

A2029-Q

2S

A2029-R

2S

A2029-S

•

Lead Free Finish/RoHS Compliant ("P" Suffix designates

RoHS Compliant. See ordering information)

•

Epoxy meets UL 94 V-0 flammability rating

•

Moisure Sensitivity Level 1

Halogen free available upon request by adding suffix "-HF"

•

A

C B

D

G

J

E

F

1

2

3

H

INCHES

MM

DIM

MIN

MAX

MIN

MAX

NOTE

A

. 04

5

.0

49

1.1

5

1.

25

C

. 0 30

.033

E

F

G

.000

.0

02

.0

00

.

050

H

J

.003

.00

6

.0

80

.1

50

B

. 04

5

.0

49

1.1

5

1.

25

0.75

0.85

0.

27

0.

37

.0

11

.0

15

0.

27

0.

17

0.5

0

0.4

3

.00

7

.0

11

.01

7

.02

0

D

.03

1TYP.

0.8

0TYP.

Micro Commercial Components

M C C

R

E

B

C
