2SC4617-Q

NPN

General Purpose

Transistors

Features

•

Complement to 2SA1774-Q/R/S

Maximum Ratings @ 25OC Unless Otherwise Specified

Symbol

Rating

Unit

VCEO

Collector-Emitter Voltage

50

V

VCBO

Collector-Base Voltage

50

V

VEBO

Emitter-Base Voltage

5

V

IC

Collector Current-Continuous

150

mA

PC

Collector Dissipation

150

mW

TJ

Operating Junction Temperature

-55 to +150

TSTG

Storage Temperature

-55 to +150

Electrical Characteristics @ 25OC Unless Otherwise Specified

Symbol

Parameter

Min

Typ

Max

Units

V(BR)CEO

Collector-Emitter Breakdown Voltage

(IC=1mAdc, IB=0)

50

---

Vdc

V(BR)CBO

Collector-Base Breakdown Voltage

(IC=50uAdc, IE=0)

50

---

Vdc

V(BR)EBO

Collector-Emitter Breakdown Voltage

(IE=50uAdc, IC=0)

5

---

Vdc

ICBO

Collector Cutoff Current

(VCB=30Vdc, IE=0Vdc)

---

0.5

Adc

IEBO

Emitter Cutoff Current

(VEB=4Vdc, IC=0Vdc)

---

0.5

Adc

hFE

DC Current Gain

(IC=1mAdc, VCE=6Vdc)

120

---

560

---

VCE(sat)

Collector-Emitter Saturation Voltage

(IC=50mAdc, IB=5mAdc)

---

0.4

Vdc

fT

Transition Frequency

(VCE=12Vdc, IC=2mAdc, f=100MHz)

---

180

---

MHz

Cob

Output Capacitance

(VCB=12Vdc, f=1.0MHz, IE=0)

---

2.0

3.5

pF

Classification OF hFE

Rank

Q

R

S

Range

120-270

180-390

270-560

Marking

BQ

BR

BS

SOT-523

INCHES

MM

DIM

MIN

MAX

MIN

MAX

NOTE

A

.059

.067

1.50

1.70

B

.030

.033

0.75

0.85

C

.057

.069

1.45

1.75

D

.020 Nominal

0.50Nominal

E

.035

.043

0.90

1.10

G

.000

.004

.000

.100

H

.028

.031

.70

0.80

J

.004

.008

.100

.200

K

.010

.014

.25

.35

A

C

B

D

E

G

H

J

K

omponents

20736 Marilla

Street Chatsworth

!"#

$% !"#

MCC

Revision: C

2014/03/07

TM

Micro Commercial Components

E

B

C

www.mccsemi.com

1 of 3

2SC4617-R

2SC4617-S

•

Lead Free Finish/RoHS Compliant ("P" Suffix designates

RoHS Compliant. See ordering information)

•

Epoxy meets UL 94 V-0 flammability rating

•

Moisure Sensitivity Level 1

DIMENSIONS

Halogen free available upon request by adding suffix "-HF"

•
