Technical Specifications (KNP-R)

Type

MIL -

R-26E

Power Rating (W)

Max. Working

Voltage (V)

Resistance Range (Ω)

Dimensions

(Unit: mm)

U (275℃) V (375℃) U (275℃)

V (375℃)

0.1%,

0.25%, 0.5%

1%, 2%,

3%, 5%

L±0.81 D±0.81 d±0.1

KNP-R1/4

-

0.40

-

20

-

10~950

1~3.4K

6.35

1.98

0.51

KNP-R1/2

RW70

0.75

-

29

-

10~1.3K

1~4.9K

7.92

1.98

0.51

KNP-R1A

-

1.00

-

53

-

1~2.7K

0.1~10.4K

10.31

2.36

0.64

KNP-R1

RW69

1.10

-

62

-

1~4.0K

0.1~15K

13.49

2.36

0.64

KNP-R2A

-

2.50

3.25

138

157

1~8.6K

0.01~32.3K 12.70

5.33

0.81

KNP-R2

RW79

3.00

3.75

135

148

1~5K

0.01~2K

13.49

4.06

0.81

KNP-R3A

-

3.00

3.75

135

148

1~6.5K

0.01~34.5K 14.27

5.33

0.81

KNP-R3

-

3.25

4.75

185

220

1~11.4K

0.01~42.1K 20.62

5.33

1.02

KNP-R4

RW67

4.00

5.50

210

250

1~12.7K

0.01~47.1K 15.88

7.62

1.02

KNP-R5

RW74

5.00

6.50

330

376

0.5~24.5K

0.01~51K

22.22

7.62

1.02

KNP-R7

RW68

7.00

9.00

504

576

0.5~41.4K

0.01~75K

30.94

9.52

1.02

KNP-R10

RW78

10.00

13.00

799

911

0.5~71.3K

0.01~82K

45.21

9.52

1.02

KNP-R Power Derating Curve

Power Precision Wire wound Resistor (KNP-R) Dimensions

Temperature Coefficient: 1 Ω and below ± 150 ppm/℃, 1 Ω to 9.9 Ω ± 100 ppm/℃, 10 Ω and above ± 100 ppm/℃, (50 ppm/℃

on request)
