CTMLP100804AF

Series

From 0.56µH to 4.7µH

SPECIFICATIONS

DCR

Rated Current

Part

Inductance

Test

±30%

Max.

Number

(µH)

Frequency

(

W)

(mA)

CTMLP100804AF-R56_

0.56

1.0MHz, 200mV

0.05

1300

CTMLP100804AF-1R0_

1.0

1.0MHz, 200mV

0.11

1200

CTMLP100804AF-1R5_

1.5

1.0MHz, 200mV

0.13

1100

CTMLP100804AF-2R2_

2.2

1.0MHz, 200mV

0.15

1000

CTMLP100804AF-3R3_

3.3

1.0MHz, 200mV

0.18

1000

CTMLP100804AF-4R7_

4.7

1.0MHz, 200mV

0.25

900

Not Shown at Actual Size

CHARACTERISTICS

PHYSICAL DIMENSIONS

PAD LAYOUT

Description: SMD Multi-layer Power Chip Inductor. Magnetically

shielded.

Applications: Cellular phones, Power modules, DC/DC

converters, Digital cameras, DVD, Portalble devices, etc.

Operating Temperature: -55°C to 125°C (including self - temp.

rise).

Rated Current: For a 40°C temperature rise from 25°C ambient

with current.

Inductance Tolerance: ±20% (M), ±30% (N)

Packaging: Tape & Reel.

Additional Information: Additional electrical & physical

information available upon request.

Samples available. See website for ordering information.

A

B

D

C

Ferrite

D

Terminal

Electrode

2.7~3.5

2.0~2.6

1.3~1.9

A

B

C

D

Max.

2.5 ± 0.20

2.0 ± 0.20

1.0

0.6 ± 0.2

0.098 ± 0.008

0.079 ± 0.008

0.039

0.024 ± 0.008

Size

mm

inches

Unit: mm

Please specify tolerance code when ordering.

CTMLP100804AF-R56_

M = ±20%, N = ±30%
