Online Download

Ordering Information

Part Number

Intel CPU

RAM

2.5" Drive

mSATA Display

GbE

PoE

USB

DIO

COM

MiniPCIe

SIM Holder

Power Input

Operating

Temperature

ARK-2151V-S6A1E

Intel Celeron

2980U 1.6 GHz

Up to 8GB

1

1

1 x HDMI

1 x VGA

2

N/A

2 x USB2.0

2 x USB3.0

6Di

2Do

4

3 x Full Size

1 x Half Size

3

-20 ~ 60° C

ARK-2151V-S9A1E

Intel i5-4300U

1.9 GHz

4

2

Dimensions

Unit: mm

ARK-2151V

Packing List

Part Number

Description

-

1 x ARK-2151 Unit

-

1 x Driver/Utility CD/Manual

-

1 x User Manual (Simplified Chinese)

1652000049

3-pole phoenix power block 3.81mm

1750001782

1 x GPS antenna Active with 5M SMA cable

1652003235

10-Pin DIO plug in block

Embedded OS

Part Number

Description

2070013560

ARK-2151V-S6A1E WES7 E OS image

2070013568

ARK-2151V-S9A1E WES7 E OS image

2070013599

ARK-2151V-S6A1E WE8S OS image

2070013600

ARK-2151V-S9A1E WE8S OS image

2070014978

ARK-2151V WES7 P OS image (10MUI, 64bit)

2070014995

ARK-2151V Win10 IoT Enterprise OS image (US, 64bit)

*Default BIOS is supported for 64-bit OS installation, BIOS 32-bit OS is supported by project

Optional Items

Part Number

Description

96PSA-A120W19T2

AC-to-DC Adapter

1702002600

Power Cable 3-pin 180cm, USA type

1702002605-02

Power Cable 3-pin 183cm, Europe type

1700018704

Power Cable 3-pin 183cm, UK type

AMK-V004E

VESA mounting kit

AMK-R004E

DIN-rail mounting kit

ARK-2151V-S6A1E External I/O Mechanical Layout/Drawing

Front Panel

Rear Panel

Front Panel

Rear Panel

ARK-2151V-S9A1E External I/O Mechanical Layout/Drawing

252.50

264.50

238.20

Ø8.0

Ø3.8

75.1

ON/OFF

SSD LED

PWR LED

VGA

USB 3.0

HDMI

LAN1

LAN2

Digital IO

SSD RESET

Optional IO 2

USB 2.0

LINE-OUT

DC INPUT

Optional IO 1

RS-232/422/485

MIC

LINE-IN

POE

LINE-OUT

DC INPUT

Digital IO

MIC

LINE-IN

ON/OFF

SSD LED

PWR LED

VGA

USB 3.0

HDMI

LAN1

LAN2

SSD RESET

Optional I/O

USB 2.0

DIN Rail

VESA mount

Wall mount
