SMD Shielded Flat Wire Power Choke

15

ALLIED COMPONENTS INTERNATIONAL

949-356-1780

www.alliedcomponents.com

RoHS

REVISED 10/03/2017

Features

•Magnetically Shielded Construction

•Ultra High Saturation Current up to 90A

•Low DC Resistance

•Expanded operating temp range

•Suitable for pick and place

Electrical

Inductance Range: 0.19µH to 10µH

Tolerance: 20% over entire range

Test Frequency: 100KHz, 0.25V

Operating Temp: -55ºC to +125ºC

Irms: Current at which the temperature

would rise by approximately 40°C

Isat: Current at which The Inductance will

drop by approximately 25%

Under no condition should the part exceed

125°C

Solderability: 230ºC ±5°C for 4 ±1 sec.

Solder Heat Resistance: 260ºC ±5ºC for

10 ±1 sec.

Test Equipment

(L): HP4284A LCR meter

DCR: Milli-ohm meter

Resistance to Soldering Heat

Physical

Packaging: 1000pcs per 13 inch reel

Marking: EIA Inductance Code

All specifications subject to change without notice.

Allied

Part

Number

Inductance

(µH)

Irms

(A)

Test

Frequency

(KHz, 0.25V)

Tolerance

(±%)

DCR

(mΩ)

Max

40.0

31.5

26.0

27.5

23.0

17.5

15.0

12.0

10.0

9.5

8.5

8.0

6.8

Isat

(A)

Typ

PCSFW104B

PCSFW104B-R19M

PCSFW104B-R22M

PCSFW104B-R36M

PCSFW104B-R47M

PCSFW104B-R56M

PCSFW104B-R68M

PCSFW104B-1R0M

PCSFW104B-1R5M

PCSFW104B-2R2M

PCSFW104B-3R3M

PCSFW104B-4R7M

PCSFW104B-5R6M

PCSFW104B-6R8M

PCSFW104B-100M

0.19

0.22

0.36

0.47

0.56

0.68

1.0

1.5

2.2

3.3

4.7

5.6

6.8

10

20

100

0.95

1.40

1.60

1.80

2.40

4.10

5.80

9.00

11.80

16.50

19.30

23.30

36.50

90.0

60.0

38.0

49.0

42.0

36.0

27.5

25.6

18.6

17.0

16.0

13.5

12.0

100

A

B

C

D

E

F

G

H

10.4 Max

4.0 Max

2.0 ±0.5

4.0

11.5 Max

2.9 ±0.5

3.5

6.0

230

200

150

60 - 120 Sec

Time (Sec)

Preheating

Soldering

Cooling

Peak: 245°C ±5 °C, 5 ±0.5 Sec

230°C or more 30-60 Sec

Recommended Reflow Solder Profile

Dimensions: (mm)
