VBO20-16AO2 datasheet(1/2 Pages) IXYS

部件名	VBO20-16AO2

功能描述	Single Phase Rectifier Bridge - Standard and Avalanche Types

PDF	2 Pages

Scroll/Zoom	100%

制造商	IXYS [IXYS Corporation]

网页	http://www.ixys.com

标志

1 / 2 page

1 - 2

IXYS reserves the right to change limits, test conditions and dimensions.

VBO 20

I

dAV

= 31 A

V

RRM = 800-1600 V

Standard and Avalanche Types

V

RSM

V

BRmin①

V

RRM

Standard

Avalanche

V

Type

900

800

VBO 20-08NO2

1300

1230

1200

VBO 20-12NO2

VBO 20-12AO2

1500

1430

1400

VBO 20-14NO2

VBO 20-14AO2

1700

1630

1600

VBO 20-16NO2

VBO 20-16AO2

① For Avalanche Types only

Symbol

Test Conditions

Maximum Ratings

I

dAV

②

T

C = 85°C, module

31

A

I

dAVM

module

40

A

P

RSM

T

VJ

= T

VJM

t = 10

µs

3.4

kW

I

FSM

T

VJ = 45°C;

t = 10 ms (50 Hz), sine

300

A

V

R = 0

t = 8.3 ms (60 Hz), sine

315

A

T

VJ = TVJM

t = 10 ms (50 Hz), sine

250

A

V

R = 0

t = 8.3 ms (60 Hz), sine

265

A

I2t

T

VJ = 45°C

t = 10 ms (50 Hz), sine

450

A2s

V

R = 0

t = 8.3 ms (60 Hz), sine

420

A2s

T

VJ = TVJM

t = 10 ms (50 Hz), sine

312

A2s

V

R = 0

t = 8.3 ms (60 Hz), sine

290

A2s

T

VJ

-40...+150

°C

T

VJM

150

°C

T

stg

-40...+125

°C

V

ISOL

50/60 Hz, RMS

t = 1 min

3000

V~

I

ISOL ≤ 1 mA

t = 1 s

3600

V~

M

d

Mounting torque (M5)

1.5-2

Nm

(10-32 UNF)

13-18

lb.in.

Weight

typ.

15

g

Features

• Avalanche rated parts available

• Package with DCB ceramic base plate

• Isolation voltage 3600 V~

• Planar passivated chips

• Low forward voltage drop

• ¼" fast-on terminals

• UL registered E 72873

Applications

• Supplies for DC power equipment

• Input rectifiers for PWM inverter

• Battery DC power supplies

• Field supply for DC motors

Advantages

• Easy to mount with one screw

• Space and weight savings

• Improved temperature and power cycling

Symbol

Test Conditions

Characteristic Values

I

R

V

R

= V

RRM;TVJ = 25°C

≤

0.3

mA

V

R

= V

RRM;TVJ = TVJM

≤

5mA

V

F

I

F

= 55 A;

T

VJ = 25°C

≤

1.6

V

T0

For power-loss calculations only

0.85

V

r

T

VJ = TVJM

14

m

Ω

R

thJC

per diode, DC current

3.0

K/W

per module

0.75

K/W

R

thJK

per diode, DC current

3.4

K/W

per module

0.85

K/W

d

S

Creeping distance on surface

13

mm

d

A

Creepage distance in air

③

9.5

mm

a

Max. allowable acceleration

50

m/s2

Dimensions in mm (1 mm = 0.0394")

Data according to IEC 60747 and refer to a single diode unless otherwise stated

② for resistive load at bridge output, ③ with isolated fast-on tabs.

Single Phase

Rectifier Bridge

~

+

–

+

–

~
