Notes

A. Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.

B. Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.

C. The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled

to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp

Page 2 of 3

Level 17 (LO Power +17 dBm) 10 to 2500 MHz

High Reliability Mixer

Demo Board MCL P/N: TB-12

Suggested PCB Layout (PL-079)

Maximum Ratings

Pin Connections

LO

2

RF

1

IF

3

GROUND

4,5,6

REV. A

M151107

SYM-R252HW+

ED14689/1

DJ/TD/CP/AM

160516

LO

IF

RF

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+17dBm

LO

+17dBm

LO

+17dBm

LO

+17dBm

LO

+17dBm

Typical Performance Data

Electrical Schematic

SYM-R252HW+

Features

• wideband, 10 to 2500 MHz

• good L-R isolation, 40 dB typ.

• good L-I isolation, 40 dB typ.

• high IP3, 23 dBm typ.

• hermetically sealed ceramic quad

Applications

• CDMA

• GSM

• DCS

• PCN

• Base station

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

200mW

IF Current

40mA

40.10

10.00

6.24

34.15

44.21

1.04

1.70

100.10

70.00

6.36

34.16

45.12

1.03

1.62

500.10

470.00

6.69

33.15

43.54

1.23

1.65

800.10

770.00

6.71

33.73

41.53

1.51

1.64

900.10

870.00

6.68

34.17

42.23

1.62

1.63

1000.10

970.00

6.66

35.58

41.39

1.68

1.60

1200.10

1170.00

6.50

38.88

41.48

1.80

1.58

1300.10

1270.00

6.41

41.19

44.24

1.81

1.59

1400.10

1370.00

6.33

44.46

44.18

1.77

1.62

1500.10

1470.00

6.29

44.97

42.19

1.72

1.65

1600.10

1570.00

6.30

47.33

41.51

1.64

1.65

1700.10

1670.00

6.37

51.03

42.00

1.60

1.66

1800.10

1770.00

6.50

57.24

41.32

1.65

1.67

1900.10

1870.00

6.75

51.76

40.12

1.69

1.65

2000.10

1970.00

7.07

45.66

38.89

1.80

1.63

2100.10

2070.00

7.32

41.25

38.08

1.91

1.60

2200.10

2170.00

7.50

38.05

38.05

1.91

1.56

2300.10

2270.00

7.69

36.33

38.24

1.90

1.52

2400.10

2370.00

7.75

35.35

38.66

1.90

1.50

2530.10

2500.00

7.52

34.20

40.40

1.72

1.50

Outline Drawing

Permanent damage may occur if any of these limits are exceeded.

Electrical Specifications at 25°C

Parameter

Min.

Typ.

Max.

Unit

Frequency Range, RF

10

—

2500

MHz

Frequency Range, LO

10

—

2500

MHz

Frequency Range, IF

10

—

500

MHz

Conversion Loss

—

6.5

9.1

dB

LO to RF Isolation

24

40

—

dB

LO to IF Isolation

28

40

—

dB

IP3

—

23

—

dBm

RF Input Power at 1 dB Compression

—

+14

—

dBm

Outline Dimensions (

)

inch

mm

PCB Land Pattern

Suggested Layout,

Tolerance to be within

±.002

A

B

C

D

E

F

G

H

J

K

.38

.50

.23 .020 .075 .250 .425 .187 .050 .050

9.65 12.70

5.84

0.51

1.91

6.35 10.80

4.75

1.27

1.27

L

M

N

P

Q

R

S

T

wt.

.070 .270 .540 .060 .095 .445 .208 .415

grams

1.78

6.86 13.72

1.52

2.41 11.30

5.28 10.54

0.8

CASE STYLE: TTT881

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Available Tape and

Reel

at no extra cost

Reel Size

Devices/Reel

7”

10, 20, 50, 100, 200

13”

500
