FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

Mid-Band

m

Total

Range

Max.

L

M

U

L

M

U

f

—

X

σ

Max.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ.

2-1000

DC-1000

5.7

0.10

7.0

9.5

68 45

45 30

36 20

55 40

32 22

22 12

15

L = low range [f

M = mid range [10 f

U = upper range [f

m= mid band [2f

1 dB COMP.: +5 dBm typ.

Phase detection, positive polarity

Page 1 of 2

Notes

A. Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.

B. Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.

C. The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled

to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±

� .002

Level 10 (LO Power +10 dBm) 2 to 1000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-03

Suggested PCB Layout (PL-052)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

3

IF

2

GROUND

1,4,5

Outline Drawing

Electrical Specifications

REV. A

M151107

ADE-R2ASKLH+

ED-12873/7

WL/TD/QL

150624

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 5.7 dB typ.

• excellent L-R isolation, 45 dB typ.

• low profile package

• aqueous washable

• protected by US Patent 6,133,525

Applications

• VSAT systems

• instrumentation

• cellular

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

ADE-R2ASKLH+

CASE STYLE: CD542

2.00

32.00

6.04

86.65

52.03

1.48

2.33

5.00

35.00

5.39

87.44

51.43

1.22

2.33

10.00

40.00

5.25

88.82

50.52

1.13

2.33

55.00

85.00

5.19

84.09

43.63

1.06

2.30

100.00

130.00

5.22

69.23

40.93

1.05

2.31

200.00

230.00

5.30

57.05

37.28

1.01

2.40

260.00

290.00

5.22

53.30

35.30

1.02

2.29

300.00

330.00

5.32

49.85

34.96

1.03

2.53

360.00

390.00

5.39

46.44

33.40

1.05

2.36

400.00

430.00

5.50

45.05

32.18

1.10

2.66

460.00

490.00

5.70

43.50

30.28

1.11

2.52

500.00

530.00

5.64

42.39

29.49

1.15

2.67

600.00

630.00

5.59

40.59

25.59

1.21

2.64

650.00

680.00

5.91

39.93

24.64

1.17

3.00

700.00

730.00

6.30

38.50

23.90

1.19

2.68

750.00

780.00

6.65

38.25

24.38

1.31

3.40

800.00

830.00

6.97

35.97

23.21

1.48

2.68

850.00

880.00

7.13

36.40

22.85

1.67

3.45

900.00

930.00

6.99

33.46

21.20

1.85

2.87

1000.00

1030.00

7.18

29.74

18.61

2.25

3.16

Permanent damage may occur if any of these limits are exceeded.

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Available Tape and

Reel

at no extra cost

Reel Size

Devices/Reel

7”

20, 50, 100, 200, 500

13”

500,1000
