PCB Land Pattern

Suggested Layout,

Tolerance to be within ±

� .002

Level 10 (LO Power +10 dBm) 300 to 4000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-03

Suggested PCB Layout (PL-052)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

3

IF

2

GROUND

1,4,5

Outline Drawing

Electrical Specifications

REV. A

M151107

ADE-R30WLH+

ED-12873/3

WL/TD/QL

150624

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• ultra wideband, 300 to 4000 MHz

• hermetically sealed ceramic quad

• low conversion loss, 7.5 dB typ.

• excellent L-R isolation, 40 dB typ.

• low profile package

• aqueous washable

• protected by US Patent 6,133,525

Applications

• cellular

• PCN

• instrumentation

• ISM

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

ADE-R30WLH+

CASE STYLE: CD542

220.00

250.00

6.99

55.00

41.71

3.67

9.48

320.00

350.00

6.05

51.10

36.54

2.29

5.16

520.00

550.00

5.67

47.81

32.60

1.43

3.60

740.00

770.00

5.31

44.14

29.98

1.23

2.87

960.00

990.00

6.57

43.31

29.04

2.63

2.35

1180.00

1210.00

6.32

46.52

20.93

3.15

1.73

1400.00

1430.00

6.68

53.58

16.16

3.11

1.59

1620.00

1650.00

6.70

47.73

14.37

2.49

1.82

1840.00

1870.00

7.08

46.42

13.36

3.62

2.10

1940.00

1970.00

7.30

45.49

13.49

3.93

2.30

2160.00

2190.00

7.71

44.51

13.71

4.40

2.59

2380.00

2410.00

8.05

42.37

13.46

4.30

2.94

2500.00

2530.00

8.21

40.68

13.46

4.37

3.18

2720.00

2750.00

8.09

39.37

13.00

4.54

3.34

2940.00

2970.00

7.71

39.78

11.97

3.87

3.54

3160.00

3190.00

7.48

40.13

10.49

3.37

3.25

3380.00

3410.00

6.88

43.93

11.96

2.82

2.79

3600.00

3630.00

6.49

40.09

14.32

2.25

3.25

3820.00

3850.00

6.51

36.86

16.70

1.84

4.37

4040.00

4070.00

7.04

38.40

18.41

1.65

5.79

Permanent damage may occur if any of these limits are exceeded.

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Available Tape and

Reel

at no extra cost

Reel Size

Devices/Reel

7”

10, 20, 50, 100, 200, 500

13”

500, 1000
