FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

Mid-Band

m

Total

Range

Max.

L

M

U

L

M

U

f

—

X

σ

Max.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ.

10-1000

DC-800

6.8

0.10

7.8

8.3

70 55

60 40

47 37

40 26

33 20

26 13

16

L = low range [f

M = mid range [10 f

U = upper range [f

m= mid band [2f

1 dB COMP.: +1 dBm typ.

Page 1 of 2

Notes

A. Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.

B. Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.

C. The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled

to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±

� .002

Level 7 (LO Power +7 dBm) 10 to 1000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-03

Suggested PCB Layout (PL-052)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

3

IF

2

GROUND

1,4,5

Outline Drawing

Electrical Specifications

REV. A

M151107

ADEX-R10+

ED-12872/4

WL/TD/CP

150624

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 7.0 dB typ.

• excellent L-R isolation, 60 dB typ.

• flat conversion loss, ±0.2 dB typ. over entire band

• good VSWR, 2:1 typ. for LO,

1.3:1 typ. for RF, 1.2:1 typ. for IF

• good performance to 1500 MHz

• low profile package

• aqueous washable

• protected by US Patent 6,133,525 and 6,947,717

Applications

• cellular

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+7dBm

LO

+7dBm

LO

+7dBm

LO

+7dBm

LO

+7dBm

ADEX-R10+

10.10

40.10

6.25

64.76

56.08

1.29

2.06

70.10

100.10

6.59

67.01

40.99

1.39

1.75

130.10

160.10

6.64

67.47

36.34

1.33

1.84

190.10

220.10

6.53

71.13

34.52

1.37

1.78

250.10

280.10

6.67

76.47

33.57

1.38

1.80

310.10

340.10

6.60

65.84

32.17

1.37

1.86

370.10

400.10

6.59

60.70

31.37

1.40

1.87

430.10

460.10

6.55

54.79

29.87

1.39

1.91

490.10

520.10

6.57

53.46

29.02

1.38

1.98

550.10

580.10

6.65

53.03

27.88

1.37

2.01

610.10

640.10

6.58

50.93

26.59

1.34

2.06

670.10

700.10

6.50

47.52

25.33

1.36

2.11

730.10

760.10

6.67

45.16

24.43

1.35

2.15

790.10

820.10

6.74

44.18

23.85

1.31

2.26

850.10

880.10

6.85

45.23

23.02

1.28

2.29

910.10

940.10

6.87

47.66

22.46

1.19

2.32

970.10

1000.10

6.48

50.13

21.53

1.10

2.35

1030.10

1060.10

6.27

55.18

19.99

1.02

2.32

1090.10

1120.10

6.14

53.76

18.95

1.15

2.43

1150.10

1180.10

6.10

47.59

18.31

1.26

2.49

CASE STYLE: CD542

Permanent damage may occur if any of these limits are exceeded.

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Available Tape and

Reel

at no extra cost

Reel Size

Devices/Reel

7”

20, 50, 100, 200, 500

13”

500,1000
