MCSO2EH 1/4

v1.0

MCSO2EH

MCSO2EH

5.0V High Frequency Oscillator for

5.0V High Frequency Oscillator for

Extreme Environments

Extreme Environments

Suitable for Avionics, Down-hole, Geothermal etc

Extreme temperature ranges up to 210°C

High stability & low ageing under extremes

High shock & vibration resistance

Optional tinned pads (Ag/Cu/Zn)

Option Code

CONFIGURABLE OPTIONS

Parameter

Frequency

Frequency stability

see note below

Any

±100ppm max over -55 to +125°C

C

±150ppm max over -55 to +150°C

E

±300ppm max over -55 to +175°C

D

±400ppm max over -55 to +210°C

G

Enable / disable function

Any

None (pad 1 NC)

Active (control via pad 1)

E

Terminations

Any

Gold plated pads

Tinned Ag/Cu/Zn

T

Frequency stability is inclusive of calibration @ 25°C, operating temperature range, supply voltage change,

load change and long term ageing (1,000hrs at T

).

*

*

MAX
