Technical Specifications

Transmitters:

SABRE-T

Enclosure Rating:Standard IPx8

Battery Type:

4 x AAA (supplied)

Battery Life:

5 years @ approx 100 1/2second presses p/day

Dimensions:

154 x 85 x 48mm

Changing the Battery: Remove the six fixing screws, remove battery and replace note polarity

Receiver Decoder:

TRAP-RX

Enclosure Rating

IP68

Dimensions

130 x 112 x 42 mm (not including antenna)

Storage Temperature:

-10 to +70

Operating Temperature:

-10 to +50

*The relay contacts in this unit are for functional use only and must not be used for isolation purposes

Approvals Information:



All RF Solutions products are manufactured in accordance with our ISO:9001 Quality System



Further information available on request.

Electrical Characteristics

Min

Typical

Max

Units

Supply Voltage

6V

V

Frequency:

869.500

MHz

RF Output Power (ERP) @ 868 MHz

-

20

dBm

ELECTRICAL CHARACTERISTICS

MIN

TYPICAL

MAX

DIMENSION

Supply Voltage

12

12

32

V ac or dc

Relay Rating* (230Vac) RLY1-4

5

12

A

Supply Current :

Quiescent

All relays operating*

40

140

mA

Time delay from Tx on Switch to Rx Relay operation

20

mS

Time delay from Tx sw relax to Rx Relay release

20

mS

RF Solutions Ltd. Recycling Notice

Meets the following EC Directives:

DO NOT

Discard with normal waste, please recycle.

ROHS Directive 2002/95/EC

Specifies certain limits for hazardous substances.

WEEE Directive 2002/96/EC

Waste electrical & electronic equipment. This product must be disposed of

through a licensed WEEE collection point. RF Solutions Ltd., fulfils its WEEE

obligations by membership of an approved compliance scheme.

Waste Batteries and Accumulators

Directive 2006/66/EC

Where batteries are fitted, before recycling the product, the batter-

ies must be

removed and disposed of at a licensed

collection point.

Environment Agency producer registration number: WEE/

JB0104WV.
