1.

Open the enclosure by removing fixing screws from the enclosure

2.

Remove the antenna and slide out the circuit board.

3.

Connect the power supply screw terminals 12-32V ac or dc to the supply terminals.

4.

Wire your desired connections to the relay switches

5.

Once all required wiring is complete, use the handheld QUANTA transmitter to switch the outputs on and

off.

6.

As supplied, the handheld will operate the outputs - button 1 to output 1, button 2 to output 2 etc.

7.

Change the output functions to latching, / Momentary Operation.

Relay Connections when

Transmitter NOT Operating

Relay Connections when

Transmitter OPERATING

Relay

Relay

Relay

12V

0V

COM

NO

NC

Supply

Terminals

TRAP-RX
