background image

https://www.phoenixcontact.com/pi/products/2966980

07/23/2018 Page 1 / 4

Relay Module - PLC-RSC- 36DC/21AU - 2966980

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PLC-INTERFACE, comprising PLC-BSC.../21 basic terminal block with screw connection and plug-in

miniature relay with multi-layer contact, for mounting on NS 35/7.5 DIN rail, 1 PDT, 36 V DC input voltage

The figure shows the version PLC-

RSC-24DC/21

Key Commercial Data

Packing unit

10 STK

Minimum order quantity

1000 STK

GTIN

GTIN

4017918410643

Sales Key

08

Technical data

Note

Utilization restriction

EMC: class A product, see manufacturer's declaration in the download

area

Dimensions

Width

6.2 mm

Height

80 mm

Depth

94 mm

Ambient conditions

Ambient temperature (operation)

-25 °C ... 60 °C

Ambient temperature (storage/transport)

-40 °C ... 85 °C

Coil side

Nominal input voltage UN

36 V DC

Contact side

Contact type

1 PDT
