Pollution degree

2

Surge voltage category

III

Mounting position

Any

Assembly instructions

In rows with zero spacing

Connection data

Type of connection

Screw connection

Conductor cross section solid min.

0.14 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section stranded min.

0.14 mm²

Conductor cross section stranded max.

2.5 mm²

Conductor cross section AWG/kcmil min.

26

Conductor cross section AWG/kcmil max

14

Stripping length

8 mm

Screw thread

M3

Certificates / Approvals

Certification

CUL, CUL Listed, GL, GOST, UL, UL Listed

Accessories

Item

Designation

Description

Assembly

0801762

NS 35/ 7,5 CU UNPERF

2000MM

DIN rail, material: Copper, unperforated, height 7.5 mm, width 35

mm, length: 2 m

0801733

NS 35/ 7,5 PERF 2000MM

DIN rail, material: Steel, galvanized and passivated with a thick

layer, perforated, height 7.5 mm, width 35 mm, length: 2 m

0801681

NS 35/ 7,5 UNPERF 2000MM

DIN rail, material: Steel, unperforated, height 7.5 mm, width 35

mm, length: 2 m

0801377

NS 35/ 7,5 V2A UNPERF

2000MM

DIN rail, Width: 35 mm, Height: 7.5 mm, Length: 2000 mm,

Color: silver

1201756

NS 35/15 AL UNPERF 2000MM

DIN rail, deep-drawn, high profile, unperforated, 1.5 mm thick,

material: Aluminum, height 15 mm, width 35 mm, length 2 m

1201895

NS 35/15 CU UNPERF 2000MM DIN rail, material: Copper, unperforated, 1.5 mm thick, height 15

mm, width 35 mm, length: 2 m
