10/28/2014   Page 2 / 6

Relay Module - PLC-RSC- 60DC/21-21AU - 2967303

Technical data

Dimensions

Width

14 mm

Height

80 mm

Depth

94 mm

Ambient conditions

Ambient temperature (operation)

-40 °C ... 60 °C

Ambient temperature (storage/transport)

-40 °C ... 85 °C

Coil side

60 V DC

10 mA

Typical response time

8 ms

Typical release time

10 ms

Operating voltage display

Yellow LED

Protective circuit

Protection against polarity reversal Polarity protection diode

Free-wheeling diode Damping diode

Contact side

Contact type

2 PDT

Contact material

AgNi, hard gold-plated

Maximum switching voltage

30 V AC

36 V DC

Minimum switching voltage

100 mV (at 10 mA)

Maximum inrush current

50 mA

Min. switching current

1 mA (at 24 V)

Limiting continuous current

50 mA

Interrupting rating (ohmic load) max.

1.2 W (at 24 V DC)

Note

the following values are applicable if a gold layer is destroyed

Maximum switching voltage

250 V AC/DC

Minimum switching voltage

5 V AC/DC

Limiting continuous current

6 A

Maximum inrush current

15 A (300 ms)

Min. switching current

10 mA

Interrupting rating (ohmic load) max.

140 W (at 24 V DC)

85 W (at 48 V DC)

60 W (at 60 V DC)

44 W (at 110 V DC)

60 W (at 220 V DC)

1500 VA (for 250 V AC)
