6.2 & 6.55 Volt Temperature Compensated

Surface Mount Zener Reference Diodes

SCOTTSD A L E DIVISION

1N821UR thru 1N829AUR-1

(or MLL821 thru MLL829-1)

ZENER

VOLTAGE

(Note 1 and 4)

ZENER

TEST

CURRENT

MAXIMUM

ZENER

IMPEDANCE

(Note 2)

MAXIMUM

REVERSE

CURRENT

VOLTAGE

TEMPERATURE

STABILITY

(

-55

(Note 3 and 4)

EFFECTIVE

TEMPERATURE

COEFFICIENT

JEDEC

TYPE NUMBER

(Notes 1, 5 & 6)

VOLTS

mA

OHMS

µA

mV

%/

1N821UR

1N821AUR

1N822UR †

1N823UR

5.9 – 6.5

5.9 – 6.5

5.9 – 6.5

5.9 – 6.5

7.5

7.5

7.5

7.5

15

10

15

15

2.0

2.0

2.0

2.0

96

96

96

48

0.01

0.01

0.01

0.005

1N823AUR

1N824UR †

1N825UR

1N825AUR

5.9 – 6.5

5.9 – 6.5

5.9 – 6.5

5.9 – 6.5

7.5

7.5

7.5

7.5

10

15

15

10

2.0

2.0

2.0

2.0

48

48

19

19

0.005

0.005

0.002

0.002

1N826UR

1N827UR

1N827AUR

1N828UR

6.2 – 6.9

5.9 – 6.5

5.9 – 6.5

6.2 – 6.9

7.5

7.5

7.5

7.5

15

15

10

15

2.0

2.0

2.0

2.0

20

9

9

10

0.002

0.001

0.001

0.001

1N829UR

1N829AUR

5.9 – 6.5

5.9 – 6.5

7.5

7.5

15

10

2.0

2.0

5

5

0.0005

0.0005

*JEDEC Registered Data.

†Double Anode; electrical specifications apply under both bias polarities.

NOTES:

1.

of 6.15 V, add a further hyphened suffix number % to the part number for desired tolerance, e.g. 1N827UR-1-2%, 1N829UR-1-1%,

1N829AUR-1%, 1N829AUR-1-1%, etc.

2.

Zener impedance is measured by superimposing 0.75 mA ac rms on 7.5 mA dc @ 25

3.

The maximum allowable change observed over the entire temperature range i.e., the diode voltage will not exceed the specified mV

change at any discrete temperature between the established limits.

4.

Voltage measurements to be performed 15 seconds after application of dc current.

5.

1N821UR-1, 1N823UR-1, 1N825UR-1, 1N827UR-1, and 1N829UR-1 also have qualification to MIL-PRF-19500/159 by adding the JAN,

JANTX, or JANTXV prefix to part numbers as well as the “-1” suffix; e.g. JANTX1N827UR-1, JANTXV1N829UR-1, etc.

6.

This product series has also been previously identified as the MLL821 thru MLL829A-1. This alternate name may still be used.

Microsemi

Scottsdale Division

8700 E. Thomas Rd. PO Box 1390, Scottsdale, AZ 85252 USA, (480) 941-6300, Fax: (480) 947-1503

Page 2

Copyright

 2003

12-19-2003 REV A
