199

C

2.2

GT25-＊DP-2.2V

B

9.65

2

+0.1

0

A

4.825

A

4.3

0.8

D

φ1.2

+0.05

0

F

E

0.6

0.4

1.2±0.05

2.2±0.05

■ M connector (PCB type)

Part No. CM-105C

●

Hand tooling

Terminal Product No.

Terminal HRS No.

Tool Part No.

Tool HRS No.

GT25H-2024SCF

775-0039-6

AP105-GT25H-2024S

901-5206-3

GT25HB-2428SCF

775-0070-6

AP105-GT25HB-2428S

901-5230-8

Note : Crimp height setting tables are available for each cable type. Pleace contact your nearest Hirose Electric account representative.

Different cables will require different crimp height settings.

HRS No.

Part No.

Applicable wire

780-0044-1 00

HT304/GT25H-2024S

GT25H-2024SCF

Note : HT304/GT25H-2024S is rated for 0.3SQ (22 AWG) or 0.5SQ (20 AWG) cable only.

HT304/GT25H-2024S can not terminate 0.2SQ (24 AWG) cable.

Part No.

HRS No.

Color

Material

/

Plating

No. of

Contacts

A

Dimension

B

Dimension

C

Dimension

D

Dimension

E

Dimension

F

Dimension

Packaging RoHS

GT25-16DP-2.2V(01)

775-0020-8 01

Light

Gray

PPS

Brass

／

Tin plating

16

26.75

22.3

15.4

23.73

15.4±0.05

23.73±0.05

1/tray

YES

GT25-24DP-2.2V(01)

775-0021-0 01

24

35.55

31.1

24.2

32.53

24.2±0.05

32.53±0.05

GT25-32DP-2.2V(01)

775-0022-3 01

32

44.35

39.9

33.0

41.33

33±0.05

41.33±0.05

GT25-40DP-2.2V(01)

775-0014-5 01

40

53.15

48.7

41.8

50.13

41.8±0.05

50.13±0.05

Straight Type

2 rows

User manuals are available. Please contact your Hirose Electric account representative.

B Crimping tools

Automatic Crimping Machine

Item

Specification

Remarks

Press capacity

1.5tons

-----

Stroke Length

30mm

-----

Number of strokes

200spm (50Hz)

240spm (60Hz)

Weight

75kg

-----

Motor

0.2kw

AC100V

Crimping speed

2,000 to 4,000 pcs/hour

-----

Specifications

BRecommended PCB pattern

Picture reference only
