HRFC Series

■Product Specifications

Ratings

Operating temperature range

-25°C to +70°C

Storage temperature range

-25°C to +70°C

Item

Test Method (IEC 61300)

Specifications

Insertion Loss

(SM)

Wavelength 1310nm (LD)

0.5dB max. (PC, AdPC, APC)

(GI)

Wavelength 1310nm (LED)

0.3dB max. (PC)

Return Loss

(SM)

Wavelength 1310nm (LD)

22dB min. (PC), 40dB min. (AdPC), 60dB min. (APC)

(GI)

22dB min. (PC)

Ferrule withdrawal

Extract zirconia gauge 2.499 ±0.0005mm

dia from split sleeve.

Phosphor bronze split sleeve

2N to 5.9N

Zirconia split sleeve

2N to 3.9N

Cable retention

(Straight pull)

98N tensile load for 1 minute.

1) Insertion loss fluctuation after test: 0.2dB max.

2) No visible damage, dislocation of clamp or cable.

Durability

(cycles, mating/un-mating)

1000 times

1) Insertion loss fluctuation after test: 0.2dB max.

2) No visible damage, cracks or part dislocation.

Vibration

Frequency: 10 to 55 Hz, single amplitude of 0.75mm,

2 hours in each of the 3 axis.

Shock

half sine shock pulse, 10 cycles in each of the 3 axis.

Humidity

(Temperature/ humidity- cycles)

-10°C to 65°C, humidity: 90% to 96% 10 cycles

Change of temperature

-40°C to +75°C 42 cycles

(Complies with Telcordia standard GR-326-CORE)

Dry heat

240 hours at 85°C

Cold

240 hours at -25°C

Salt mist

48 hours in a 5% concentration of salt mist

No significant corrosion.

■Materials

Part

Material

Plug housing

Brass, Zinc alloy

Spring

Stainless steel

Ferrule

Zirconia

Adapter

Brass

Split sleeve

Zirconia or Phosphor bronze

Receptacle

Brass
