UNI SONI C TECHNOLOGI ES CO., LTD

L8001

Preliminary

CMOS IC

www.unisonic.com.tw

1 of 6

Copyright © 2017 Unisonic Technologies Co., Ltd

QW-R502-938.d

FET BI AS CON T ROLLER



DESCRI PT I ON

The UTC L8001 is specially designed integrated circuit for

satellite receiver front-end block. It provides stable drain and gate

bias conditions for GaAs or HEMT FETs.

The UTC L8001, provide six FETs bias control respectively.

By adjusting two external resistors, it can change the FET’s bias

current to optimize the satellite receiver front end block

performances.

It generates the required negative voltage to bias the gate of

GaAs FET, and internally provides protection circuit that can

protect the FET devices during supply voltage transient. So it is

very popular in satellite receiver front end block.



FEAT U RES

* Built in FET device protection circuit

* Adjustable FET device operating current

* Stable bias control for GaAs and HEMT FETs

* Drive up to six FETs

* Wide supply voltage range



ORDERI N G I N FORM AT I ON

Ordering Number

Lead Free

Halogen Free

Package

Packing

L8001L-R20-R

L8001G-R20-R

SSOP-20

Tape Reel



M ARK I N G
