background image
INCHANGE Semiconductor
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc Silicon NPN Power Transistor
ISC253
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
VCEO(BR)
Collector-Emitter Breakdown Voltage IC=50mA ; IB= 0
80
V
VCE(sat)-1
Collector-Emitter Saturation Voltage
IC= 1.5 A; IB= 30mA
2.5
V
VCE(sat)-2
Collector-Emitter Saturation Voltage
IC= 4A; IB= 40mA
3
V
VBE(on)
Base-Emitter On Voltage
IC= 1.5A; VCE= 3V
2.5
V
ICBO
Collector Cutoff Current
VCB=80V; IE= 0
0.1
mA
IEBO
Emitter Cutoff Current
VEB= 5V; IC= 0
2
mA
hFE-1
DC Current Gain
IC= 1.5A ; VCE= 3V
750
2000
hFE-2
DC Current Gain
IC= 4A ; VCE=3V
100
