1 / 8 page  ES3AB - ES3JB Taiwan Semiconductor 1 Version:B1706 3A, 50V - 600V Surface Mount Super Fast Rectifier FEATURES ● Glass passivated junction chip ● Ideal for automated placement ● Low profile package ● Super fast recovery time for high efficiency ● Compliant to RoHS Directive 2011/65/EU and in accordance to WEEE 2002/96/EC ● Halogen-free according to IEC 61249-2-21 APPLICATIONS ● Switching mode power supply (SMPS) ● Adapters ● Lighting application ● Converter MECHANICAL DATA ● Case: DO-214AA (SMB) ● Molding compound meets UL 94V-0 flammability rating ● Part no. with suffix “H” means AEC-Q101 qualified ● Packing code with suffix "G" means green compound (halogen-free) ● Moisture sensitivity level: level 1,per J-STD-020 ● Terminal: Matte tin plated leads, solderable per J-STD-002 ● Meet JESD 201 class 2 whisker test ● Polarity: As marked ● Weight: 0.11 g (approximately) KEY PARAMETERS PARAMETER VALUE UNIT IF(AV) 3 A VRRM 50 - 600 V IFSM 100 A TJ MAX 150 °C Package DO-214AA (SMB) Configuration Single die DO-214AA (SMB) ABSOLUTE MAXIMUM RATINGS (T A = 25°C unless otherwise noted) PARAMETER SYMBOL ES 3AB ES 3BB ES 3CB ES 3DB ES 3FB ES 3GB ES 3HB ES 3JB UNIT Marking code on the device ES 3AB ES 3BB ES 3CB ES 3DB ES 3FB ES 3GB ES 3HB ES 3JB Repetitive peak reverse voltage VRRM 50 100 150 200 300 400 500 600 V Reverse voltage, total rms value VR(RMS) 30 70 105 140 210 280 350 420 V Forward current IF(AV) 3 A Surge peak forward current, 8.3 ms single half sine-wave superimposed on rated load per diode IFSM 100 A Junction temperature TJ - 55 to +150 °C Storage temperature TSTG - 55 to +150 °C |
