background image
AXC-051
PRELIMINARY
September 98
Page 2 of 4
98004-05-004-06.doc
IXYS Corporation 3540 Bassett Street, Santa Clara, CA 95054 TEL:408-982-0700 FAX:408-496-0670
IXYS Semiconductor, GmbH. Edisonstr. 15 D-68623 Lampertheim, Germany TEL:+49-6206-503-0 FAX:+49-6206-503-627
Absolute Maximum Ratings
Parameter
Conditions
Min
Max
Units
Supply Voltage
+0.5
-75
Vdc
Maximum Output Current
0
6
A
Storage Temperature
-30
110
°C
Operating Temperature
-30
85
°C
DC Electrical Specification (-30°C
≤TA ≤+85°C)
Parameter
Conditions
Min
Typ
Max
Units
Operating Voltage
-18
-72
Vdc
Rated Current
0
5
A
TA
= +25°C
0.73
Vdc
ILOAD
=0A
-30°C
≤TA ≤+85°C
0.70
Vdc
TA
= +25°C
0.74
Vdc
ILOAD
=1A
-30°C
≤TA ≤+85°C
0.73
Vdc
TA
= +25°C
0.76
Vdc
ILOAD
=2A
-30°C
≤TA ≤+85°C
0.75
Vdc
TA
= +25°C
0.80
Vdc
Voltage Drop @ VIN= -48V
ILOAD
=5A
-30°C
≤TA ≤+85°C
0.79
Vdc
Quiescent Current
-18V
≤VIN ≤-72V
0.38
0.42
0.52
mA
AC Electrical Specification (-30°C
≤TA ≤+85°C)
Operating Voltage -(18
÷ 72)V ; Output Current ILOAD=(0÷ 5)A
Parameter
Conditions
Min
Typ
Max
Units
Insertion Loss*
20Hz
÷ 10KHz @ 50Ω
55
60
dB
10Hz
÷ 10KHz
9
15
30
m
Ω
Output Impedance*
10KHz
÷ 250KHz
30
50
100
m
Ω
Line Transient Attenuation*
Transient voltage less than 0.75V
35
40
dB
Transient Output Impedance*
Idc=2A;
∆I=1A
70
110
m
Ω
* Tested with C1 & C2 [Fig.4] = 10uF Electrolytic Capacitor ; Maximum Input Noise Level = (1.3-0.1ILOAD[A])V
Attenuation (Vout[ac]/Vripple)
Test Setup
Fig.3
Load
I
Vin
LOAD
AXC051
OUT
COM
IN
3
2
1
R
1
C
2
V
OUT
C
1
A
V
V
A
V
IN
V
OUT
I
Quiescent
+
-
V
V
DROP
Vripple
Fig.4
