DataShield In-Line Surge Protector for Network

and Phone Lines, 1-Line RJ45

MODEL NUMBER: DNET1

Protects network datalines on workstations, printers, hubs and other devices from blown NIC cards,

garbled transmissions, lock-ups and hardware failures caused by surges, line noise, ESD, faulty wiring

and lightning.

Description

Tripp Lite's DNET1 provides network Ethernet line surge suppression for 100Base-T, 10Base-T, Token

Ring, AS400/Sys3x and RS422 applications. Surge suppression is handled with balanced arrays of high-

speed avalanche diodes that divert excess energies created by electrostatic discharges, faulty wiring or

lightning away from network interface connections. Tripp Lite network surge suppressors reduce blown

NIC cards, garbled network transmissions, system lock-ups and hard equipment failure by safely shunting

dataline surges to ground. Convenient RJ45 input and output connections with an included 5-inch

Ethernet patch cable enables ideal protection for network workstations, printers and other internetworking

devices with a network connection. For peace of mind, the DNET1 comes with a lifetime warranty and

RoHS-compliant design.

Features

DNET1 protects network workstations, printers and internetworking devices from surges present on

10/100Base-T, token ring, AS400/Sys3x or RS422 network lines

q

Convenient RJ45 input and output connections make for simple installation (RJ45 input/output

connections, pins 1-8, 7.5V clamping)

q

5 inch Ethernet patch cable enables ideal protection placed as close as possible to the point of use

q

Surge suppression utilizing high speed avalanche diodes divert excess energies on the network to

ground

q

RoHS Compliance

q

Lifetime Warranty

q

Highlights

Network Ethernet line surge

suppression for 100Base-T,

10Base-T, Token Ring,

AS400/Sys3x and RS422

applications

q

Ideal protection for NICs,

terminals, hubs, printers, LAN

equipment, and other

internetworking devices

q

Protects against the effects of

electrostatic discharge, faulty

wiring and lightning

q

Reduces blown NIC cards,

garbled network transmissions,

system lock-ups and hard

equipment failure

q

750A circuit breaker; 7.5V

nominal clamping voltage

q

RJ45 input and output

connections with included patch

cable

q

Package Includes

DNET1 dataline protector

q

5-in. RJ45 patch cable

q

Warranty information and

instruction manual

q
