AD8628/AD8629

Rev. C | Page 8 of 20

FREQUENCY (Hz)

–10

–20

–30

10k

100k

10M

VS = 2.7V

CL = 20pF

RL = 2kΩ

AV = 100

AV = 10

AV = 1

Figure 17. Closed-Loop Gain vs. Frequency at 2.7 V

FREQUENCY (Hz)

–10

–20

–30

10k

100k

10M

VS = 5V

CL = 20pF

RL = 2kΩ

AV = 100

AV = 10

AV = 1

Figure 18. Closed-Loop Gain vs. Frequency at 5 V

FREQUENCY (Hz)

300

270

240

210

180

150

120

100

10k

100k

10M

100M

VS = 2.7V

AV = 100

AV = 10

AV = 1

Figure 19. Output Impedance vs. Frequency at 2.7 V

FREQUENCY (Hz)

300

270

240

210

180

150

120

100

10k

100k

10M

100M

VS = 5V

AV = 100

AV = 10

AV = 1

Figure 20. Output Impedance vs. Frequency at 5 V

VS = ±1.35V

CL = 300pF

RL = ∞

AV = 1

TIME (4

µs/DIV)

Figure 21. Large Signal Transient Response at 2.7 V

VS = ±2.5V

CL = 300pF

RL = ∞

AV = 1

TIME (5

µs/DIV)

Figure 22. Large Signal Transient Response at 5 V
