 2 / 2 page
background image
isc website：www.iscsemi.cn
isc & iscsemi is registered trademark
2
isc P-Channel MOSFET Transistor
ISCPL45D
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNIT
BVDSS
Drain-Source Breakdown Voltage VGS=0V; ID= -250μA
-40
V
VGS(th)
Gate Threshold Voltage
VDS=VGS; ID= -250μA
-1.5
-2
-3
V
RDS(on)
Drain-Source On-Resistance
VGS= -10V; ID= -12A
12
14
mΩ
IGSS
Gate-Source Leakage Current
VGS= ±20V; VDS= 0V
±100
nA
IDSS
Drain-Source Leakage Current
VDS= -40V; VGS= 0V
-1
μ
A
VSD
Diode forward voltage
IS= -12A, VGS = 0V
-1.2
V
tr
Turn-on Rise Time
VDD=-20V,ID=-12A
VGS=-10V,RG=3Ω
18
ns
tf
Turn-Off Fall Time
24
ns
td(on)
Turn-on Delay Time
10
ns
td(off)
Turn-Off Delay Time
38
ns
