YUAN DEAN SCIENTIFIC CO.,LTD

12D-R SERIES

Rev:1 2018/10/02

General Specifications

Parameters

Conditions

Min

Typ

Max

Units

Isolation Resistance

500Vdc

1000

MΩ

Switching Frequency

Full load, nominal input

100

KHz

Operation

Temperature

-40

+85

℃

Humidity

Non Condensing

Cooling

Free air Convection

Case material

DAP

MTBF

MIL-HDBK-217F@25℃

1500000

Hours

Weight

2.7

Dimensions

19.5x7.1x10.0

Recommended Test Circuit

+Vin

+Vout

Cin

Cout

3.3V:Cin 10uF,25V

5V:Cin 10uF,25V

9V:Cin 10uF,25V

12V:Cin 10uF,25V

15V:Cin 10uF,50V

24V:Cin 10uF,50V

-Vin

-Vout

3.3V:Cout 100uF,25V

5V:Cout 100uF,25V

9V:Cout 100uF,25V

12V:Cout 100uF,25V

15V:Cout 100uF,50V

24V:Cout 100uF,50V

Rev:0 2017/8/30

Part Number

Markings and dimensions

PIN Connection

Single

+Vin

-Vin

-Vout

+Vout

12D

2.54

19.50

0.50±0.05

1.25

2.00

0.25±0.05

4.0

10.00

TOP VIEW

BOTTOM VIEW

15.24

printed face

7.10

A :

Series

B :

Input Voltage

C :

Single(S);Dual(D)

D :

Output Voltage

E :

Regulated(R)

RoHS Version

UNIT: mm

Unless otherwise specified, all tolerances are ±0.25

Packaging

Size(mm)

9.5

16.5

522

5.0
