background image
Remote On/Off Note
96D-R5 SERIES
YUAN DEAN SCIENTIFIC CO.,LTD
Rev:1.0 2018/12/17
Part Number
Input Specifications
Parameters
Conditions
Min
Typ
Max
Units
Voltage Types
2:1
Filter
Pi Type
Input surge voltage
100mS max
12V, 24V input
50
Vdc
48V input
100
Vdc
Input reflected ripple
current
Nominal Vin and
full load
20
mAp-p
Start up time
Nominal Vin and
constant resistive load
Power up
30
mS
Remote ON/OFF
30
mS
Start-up voltage
12V input
9
Vdc
24V input
18
Vdc
48V input
36
Vdc
Shutdown voltage
12V input
8
Vdc
24V input
17
Vdc
48V input
35
Vdc
Protection
Fuse Recommended
Remote ON/OFF
(Note 2)
DC-DC ON
OPEN
DC-DC OFF
Short to ground
Input current of
Remote control pin
Nominal Vin
-0.5mA ~ +0.5mA
Remote off state
input current
Nominal Vin
3mA
0V
Vp
(1)+Vin
(2)-Vin
(3)Ctrl
(4)+Vout
(5)-Vout
(6)Trim
RL
SW
a
b
Vin+
When pin3 short to pin2,D/D ON=>OFF
When pin3 leave open,D/D=>ON
control Voltage
Ra=
Vp-0.6
0.5mAΩ
0.5mA
Ra
to pin3
NPN
to pin2(-Vi)
(on/off control)
Output Specifications
Parameters
Conditions
Min
Typ
Max
Units
Voltage Tolerance
Full load@Vin(nom.)
±2
%
Short Circuit /Restart
Protection
Hiccup,
automatic recovery
Over Load Protection
nominal input
150
V
Over Voltage Protection
(Zener Diode Clamp)
3.3V Output
3.9
V
5.0V Output
6.2
V
12V Output
15 & ±15
V
15V Output
18 & ±18
V
Line Regulation
LL to HL at Full Load
±0.5
%
Load Regulation
Single
±0.5
%
Load Regulation
Dual, Balance Load,25%
to 100% load
±1.0
%
Cross Regulation
Dual (25% to 100% load)
±5.0
%
Ripple & Noise
20MHz bandwidth
100
mVp-p
Transient response
recovery time
25% load step change
250
350
us
External Trim Adj.
Range
±10% of
Output
The components used in the
above figure, together with the
manufacturers’ part numbers for
these components, are as follows:
Derating Curve
(without Heat-Sink)
-48S
C2/C3
1000pF/2KV 1808 MLCC
C1
2.2µF/100V 1812 MLCC
-24S
Single Output
4.7µF/50V 1812 MLCC 1000pF/2KV 1808 MLCC
-48D
C2/C4
1000pF/2KV 1808 MLCC
C1
2.2µF/100V 1812 MLCC
-24D
Dual Output
4.7µF/50V 1812 MLCC 1000pF/2KV 1808 MLCC
