DC-DC Converter

98DW20-R3 SERIES

20Watt 3KV Isolated

4：1 Input Voltage Range

Single & Dual Output

2” x 1”

Specifications typical at TA=25°C, nominal input voltage and

rated output current unless otherwise specified

Part Number

I

nput

Voltage

Range

Nominal Input

Voltage

Output

Voltage

Range

Output

Current

Efficiency

Vdc

No-

Load

(mA

TYP)

Full

Load

(mA

TYP)

Vdc

mA

%TYP

98DW20-24S03R3NL

9-36

7

736

3.3

4500

84

98DW20-24S05R3NL

9-36

7

968

5

4000

86

98DW20-24S12R3NL

9-36

7

946

12

1670

88

98DW20-24S15R3NL

9-36

7

946

15

1330

88

98DW20-48S03R3NL

18-75

6

368

3.3

4500

84

98DW20-48S05R3NL

18-75

6

484

5

4000

86

98DW20-48S12R3NL

18-75

6

473

12

1670

88

98DW20-48S15R3NL

18-75

6

473

15

1330

88

98DW20-110S03R3NL

40-160

5

165

3.3

4500

82

98DW20-110S05R3NL

40-160

5

214

5

4000

85

98DW20-110S12R3NL

40-160

5

211

12

1670

86

98DW20-110S15R3NL

40-160

5

211

15

1330

86

98DW20-24D12R3NL

9-36

7

946

±12

±833

88

98DW20-24D15R3NL

9-36

7

958

±15

±667

87

98DW20-48D12R3NL

18-75

6

473

±12

±833

88

98DW20-48D15R3NL

18-75

6

479

±15

±667

87

98DW20-110D12R3NL

40-160

5

211

±12

±833

86

98DW20-110D15R3NL

40-160

5

214

±15

±667

85

YUAN DEAN SCIENTIFIC

YUAN DEAN SCIENTIFIC CO.,LTD

98DW20-R3 SERIES

Temperature Derating Graph

Input Specifications

Parameters

Conditions

Min

Typ

Max

Units

Voltage Types

4:1

Surge Voltage

(1 sec. max.)

24V models

50

Vdc

48V models

100

Vdc

110V models

170

Vdc

Input Filter

PI Type

Reflected ripple current

30

mAp-p

Remote ON/OFF

(Refer to –Vin PIN)

Positive Logic

ON : Open

3

12

Vdc

OFF: Short

0

1.2

Vdc

Input current of Ctrl PIN

0.5

mA

Remote off input current

3

mA

Rev:0 2018/10/31

FEATURES：

20 Watt Package

4:1Wide Input Voltage

100% Burned In

High Efficiency To 89%

Customized Solutions Available

Remote Control:On/Off

UL94V-0 Package Material

Operating Temperature:-40℃ TO +87℃

3 Years Warranty

Regulated Output Types

EN 50155 Approval For Railway Applications
