3
Technical Data
4407
Effective June 2015
FP0906
High frequency, high current power inductors
www.eaton.com/elx
0
5
10
15
20
25
30
35
40
45
50
Total Loss (W)
Temperature rise vs. total loss
Core loss vs Bp-p
0.00001
0.0001
0.001
0.01
0.1
1
10
Bp-p (Gauss)
1.0MHz
500kHz
300kHz
100kHz
30%
40%
50%
60%
70%
80%
90%
100%
110%
% of Isat1
% of OCL vs. % of Isat1
+125C
+85C
+25C
-40C
30%
40%
50%
60%
70%
80%
90%
100%
110%
% of Isat1
% of OCL vs. % of I sat1
+125C
+85C
+25C
-40C
FP0906R1-R22 to R30
FP0906R1-R10 to R18
Inductance characteristics
