Technical Data 10007

Effective June 2017

FP1007R6

High frequency, high current power inductors

www.eaton.com/electronics

Packaging information - mm

Dimensions- mm

1. Open Circuit Inductance (OCL) Test Parameters: 100kHz, 0.10Vrms, 0.0Adc

2. Full Load Inductance (FLL) Test Parameters: 100kHz, 0.1Vrms, Isat1

3. Irms: DC current for an approximate temperature rise of 40°C without core loss. Derating is

necessary for AC currents. PCB layout, trace thickness and width, air-flow, and proximity of

other heat generating components will affect the temperature rise. It is recommended that

the temperature of the part not exceed 125°C under worst case operating conditions

verified in the end application.

4. Isat1: Peak current for approximately 20% rolloff at +25°C.

5. Isat2: Peak current for approximately 20% rolloff at +100°C.

6. K-factor: Used to determine Bp-p for core loss (see graph). Bp-p = K * L

* ∆I * 10-3. Bp-p:(Gauss), K: (K-factor from table), L: (Inductance in nH),

∆I (peak-to-peak ripple current in Amps).

7. Part Number Definition: FP1007R6-Rxx-R

FP1007R6 = Product code and size

Rxx= Inductance value in uH, R = decimal point

-R suffix = RoHS compliant

Product Specications

Part

DCR @20°C

(nH)

(nH)

(Amps)

(Amps)

(Amps)

(m)

FP1007R6-R15-R

150

108

75.0

60.0

FP1007R6-R18-R

180

129

60.0

50.0

FP1007R6-R22-R

220

158

50.0

40.0

FP1007R6-R27-R

270

194

61

41.0

33.0

0.29 ± 5%

348.8

FP1007R6-R33-R

330

237

33.0

26.5

FP1007R6-R39-R

390

280

28.0

22.5

FP1007R6-R47-R

470

338

23.5

19.0

The nominal DCR is measured from point "A" to point "B"

Part Marking: 1007R6, Rxx = Inductance value in µH. (R = Decimal point) wwllyy = Date code R = Revision level Tolerance are

±0.15mm unless otherwise specified.

Soldering surfaces to be coplanar within 0.1016mm.

PCB tolerance ±0.1mm unless otherwise specified.

24.0

±0.30

1.75

11.5

1.5 dia

1.5 dia

4.0

2.0

8.1

12.0

7.1

10.60

2

1

A

A

SECTION A-A

Supplied in Tape-and-Reel packaging, 700 parts per 13 inch diameter reel.
