Technical Data

10408

Effective June 2015

FP1008R1 and FP1008R2

High frequency, high current power inductors

www.eaton.com/elx

Core loss vs. Bp-p

0.0001

0.001

0.01

0.1

1001000

10000

Bp-p (Gauss)

20%

40%

60%

80%

100%

120%

020406080100

120140

IDC (A)

FP1008R1/R2-R120-R

20%

40%

60%

80%

100%

120%

020406080100

120

IDC (A)

FP1008R1/R2-R150-R

25°C

100°C

125°C

-40°C

25°C

100°C

125°C

-40°C

Inductance characteristics
