FP1008R1-R150-R 数据表(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FP1008R1-R150-R 数据表(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 6 page  Technical Data 10408 Effective June 2015 FP1008R1 and FP1008R2 High frequency, high current power inductors Product description • High current carrying capacity • Low core loss • Controlled DCR for sensing circuits • Inductance range from 120nH to 300nH • Current range from 38 to 112 amps • 10.8 x 8.0 mm footprint surface mount package in an 8.0 mm height • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • Servers • Multi-phase and Vcore regulators • Voltage Regulator Modules (VRMs) • Desktop VRMs and EVRDs • Data networking and storage systems • Graphics cards and battery power systems • Point-of-Load modules • DCR Sensing circuits Environmental data • Storage temperature range (Component): -40°C to +125 °C • Operating temperature range: -40°C to +125°C (ambient + self-temperature rise) • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE |
