Technical Data 10520

Effective April 2017

FP1008R5 and FP1008R6

High frequency, high current power inductors

Product features

•

High current carrying capacity

•

Low core loss

•

Magnetically shielded

•

Tight tolerance DCR for sensing circuits

•

Inductance Range from 100 nH to 300 nH

•

Current range from 36 A to 103 A

•

10.8 mm x 8.0 mm footprint surface mount

package in an 8.0 mm height

•

Moisture Sensitivity Level: 1

•

Ferrite core material

Applications

•

Multi-phase and Vcore regulators

•

Voltage Regulator Modules (VRMs) and high

power density VRMs

•

Server and desktop

•

Central processing unit (CPU)

•

Graphics processing unit (GPU)

•

Application specific integrated circuit (ASIC)

•

Data networking and storage systems

•

Graphics cards and battery power systems

•

Point-of-Loadmodules (POL)

•

DCR sensing circuits

Environmental data

•

Storage temperature range (Component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

•

Halogen free, lead free, RoHS compliant

Pb

HALOGEN

HF

FREE
