Technical Data

4126

Effective October 2015

HC8LP

Low profile, high current power inductors

www.eaton.com/elx

Rolloff

Core loss

Packaging information–mm

Supplied in tape and reel packaging, 800 parts per reel

1.75

11.5

24.0

+/-0.3

User direction of feed

11.2

HC8LP-XXX

wwllyy R

SECTION A-A

1.5 dia

+0.1/-0.0

1.5 dia

min

4.0

2.0

16.0

Ko=4.3 mm

Bo=11.2 mm

Ao=10.4 mm

Irms DERATING WITH CORE LOSS

100

110 130 150170 190

%Applied Volt-u Seconds

100kHz

200kHz

300kHz

400kHz

500kHz

OCL vs Isat

100

0102030405060708090 100 110120 130140 150160 170 180190 200 210220

%of Isat
