1 / 11 page  Technical Data 10548 Effective August 2016 HCM1A0703 Automotive grade High current power inductors Product features • AEC-Q200 Grade 1 qualified • High current carrying capacity • Magnetically shielded, low EMI • Frequency range up to 1 MHz • Inductance range from 0.1 μH to 33 μH • Current range from 1.6 A to 36 A • 7.4 mm x 7.0 mm footprint surface mount package in a 3.0 mm height • Alloy powder core material • Moisture Sensitivity Level (MSL): 1 • Halogen free, lead free, RoHS compliant Applications • Body electronics • Central body control module • Vehicle access control system • Headlamps, tail lamps and interior lighting • Heating ventilation and air conditioning controllers (HVAC) • Doors, window lift and seat control • Advanced driver assistance systems • 77 GHz radar system • Adaptive cruise control (ACC) • Automatic parking control • Collision avoidance system/Car black box system • Infotainment and cluster electronics • Active noise cancellation (ANC) • Audio subsystem: head unit and trunk amp • Digital instrument cluster • In-vehicle infotainment (IVI) and navigation • Port power/USB HUB for front and rear passengers • Chassis and safety electronics • Airbag control unit • Electronic stability control system (ESC) • Engine and Powertrain Systems • Electric pumps, motor control and auxiliaries • Powertrain control module (PCU)/Engine Control unit (ECU) • Transmission Control Unit (TCU) Environmental Data • Storage temperature range (Component): -55 °C to +155 °C • Operating temperature range: -55 °C to +155 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant Pb HALOGEN HF FREE |
