HCM1104-R56-R datasheet(1/7 Pages) EATON

部件名	HCM1104-R56-R

功能描述	High current power inductors

PDF	7 Pages

Scroll/Zoom	100%

制造商	EATON [Eaton All Rights Reserved.]

网页	https://www.eaton.com

标志

1 / 7 page

Technical Data 4370

Effective August 2018

Supersedes September 2017

HCM1104

High current power inductors

Product features

•

High current carrying capacity

•

Low core losses

•

Magnetically shielded, low EMI

•

Frequency range up to 5 MHz

•

Inductance range from 0.2 μH to 22 μH

•

Current range from 5 A to 45 A

•

11.5 mm x 10.3 mm footprint surface mount

package in a 4.0 mm height

•

Iron powder core material

Applications

•

Voltage Regulator Module (VRM)

•

Multi-phase regulators

•

Point-of-Load modules

•

Desktop and server VRMs and EVRDs

•

Base station equipment

•

Notebook and laptop regulators

•

Battery power systems

•

Graphics cards

•

Data networking and storage systems

Environmental data

•

Storage temperature range (Component):

-55 °C to +125 °C

•

Operating temperature range: -55 °C to +125 °C

(ambient + self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

Pb

HALOGEN

HF

FREE
