1 / 12 page  Technical Data 10650 Effective July 2018 MPIA25-V2 Automotive grade High current, low profile, miniature power inductors Product features • AEC-Q200 qualified • High current carrying capacity in a compact standard 1008 (2520 metric) footprint • Magnetically shielded, Low EMI • Rugged construction • Self resonant frequency (SRF) greater than 25 MHz • Inductance range from 0.33 μH to 4.7 μH • Current range from 1.2 A to 7.5 A • 2.7 mm x 2.2 mm footprint surface mount pack- age in 1.05 mm, 1.25 mm heights • Moisture Sensitivity Level (MSL): 1 Applications • Body electronics • Central body control module • Vehicle access control system • Headlamps, tail lamps, interior lighting and LED lighting • Doors, window lift and seat control • Advanced driver assistance systems • 77 GHz radar system • Basic and smart surround, and rear and front view camera • Adaptive cruise control (ACC) • Automatic parking control • Car black box system • Infotainment and cluster electronics • Active noise cancellation (ANC) • Audio subsystem: head unit and trunk amp • Digital instrument cluster • In-vehicle infotainment (IVI) and navigation Environmental data • Storage temperature range (Component): -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant • Halogen free, lead free, RoHS compliant Pb HALOGEN HF FREE |
