MPIA4020V2-R33-R 数据表(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
MPIA4020V2-R33-R 数据表(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 22 page  Technical Data 10652 Effective April 2017 MPIA40-V2 Automotive grade High current, low profile, miniature power inductors Product features • AEC-Q200 Grade 3 qualified • High current carrying capacity • Magnetically shielded, Low EMI • Rugged flexible construction • Self resonant frequency (SRF) greater than 9.5 MHz • Inductance range from 0.1 μH to 22 μH • Current range from 1.2 A to 22 A • 4.75 mm x 4.45 mm footprint surface mount package in 1.2 mm, 1.5 mm, and 2.0 mm heights • Moisture Sensitivity Level (MSL): 1 Applications • Body electronics • Central body control module • Vehicle access control system • Headlamps, tail lamps and interior lighting • Doors, window lift and seat control • Advanced driver assistance systems • 77 GHz radar system • Basic and smart surround, and rear and front view camera • Adaptive cruise control (ACC) • Automatic parking control • Car black box system • Infotainment and cluster electronics • Active noise cancellation (ANC) • Audio subsystem: head unit and trunk amp • Digital instrument cluster • In-vehicle infotainment (IVI) and navigation • Chassis and safety electronics • Airbag control unit Environmental data • Storage temperature range (Component): -55 °C to +125 °C • Operating temperature range: -55 °C to +125 °C (ambient plus self-temperature rise) • Solder reflow temperature: J-STD-020 (latest revision) compliant • Halogen free, lead free, RoHS compliant Pb HALOGEN HF FREE |
