Technical Data 2000

Effective May 2017

Supersedes June 2013

Product features

Agency information

•

UL Listed Guide JDYX & File E19180

•

UL Recognition Guide JDYX2 & File E19180

•

CSA Certification: Class No: 1422-01 &

1422-30, File 53787

Ordering

•

Specify packaging, product and option

code

ABC

1⁄4” x 1 1⁄4” Fast-acting ceramic tube fuses

•

Fast-acting, ceramic tube

•

Optional axial leads available

•

1⁄4” x 1 1⁄4” (6.4 x 31.7mm) physical size

•

Ceramic tube, nickel-plated brass endcap construction

•

UL Listed product meets standard 248-14

Specifications

Voltage

Vac Interrupting

Vdc Interrupting

Typical

Part

Ratings

Ratings* (amps)

Ratings (amps)

DC Cold

Pre-Arc

Voltage

Agency Approvals

Number

Vac

Vdc

250

V

125

V

125

V

75

V

Resistance (

Ω)**

I

2t AC†

Drop (V)

‡

UL

UR

CSA

ABC-1⁄4-R

250

125

35

10,000

–

2.950

0.0020

0.35

X

ABC-

1⁄2-R

250

125

35

10,000

–

0.587

0.0390

0.41

X

ABC-3⁄4-R

250

125

35

10,000

–

0.300

0.1450

0.32

X

ABC-1-R

250

125

35

10,000

–

0.1950

0.4310

0.3

X

ABC-1-1⁄2-R

250

125

100

10,000

–

0.131

1.1630

0.28

X

ABC-2-R

250

125

100

10,000

–

0.0890

2.1670

0.31

X

ABC-2-

1⁄2-R

250

125

100

10,000

–

0.061

4.4670

0.23

X

ABC-3-R

250

125

100

10,000

–

0.047

6.55

0.14

X

ABC-4-R

250

125

200

10,000

–

0.031

22.28

0.17

X

ABC-5-R

250

125

200

10,000

–

0.026

32.83

0.22

X

ABC-6-R

250

125

200

10,000

–

0.021

58

0.19

X

ABC-7-R

250

125

200

10,000

–

0.016

109.33

0.17

X

ABC-8-R

250

125

200

10,000

–

0.014

116.5

0.19

X

ABC-10-R

250

125

200

10,000

–

0.011

208.8

0.15

X

ABC-12-R

250

125

750

10,000

–

0.0068

133.3

0.1

X

ABC-15-R

250

125

750

10,000

–

0.00553

200.2

0.1

X

ABC-18-R

250

–

400

1000

–

0.00465

400

0.1

X

ABC-20-R

250

125

400

1000

10,000

–

0.00366

550.8

0.1

X

ABC-25-R

250

125

200

1000

400

1000

0.0028

839.3

0.09

X

X‡‡

ABC-30-R

250

125

200

1000

400

1000

0.002225

1429

0.09

X

‡‡

* Interruptingratingsmeasuredat70%-80%powerfactoronAC.Theinterruptingratingsfor18Aand20Aweremeasuredat85%-95%powerfactoronAC.The

interruptingratingsfor25Aand30Aweremeasuredat89%powerfactoronAC.

** TypicalDCcoldresistancemeasuredat<10%ofratedcurrent.

† TypicalmeltingI2tmeasuredatlistedinterruptingratingandratedvoltage.

‡ Typicalvoltagedropmeasuredat25°C±3°Cambienttemperatureatratedcurrent.

‡‡ CSAapprovalsfor25Aand30Aareat125Vac-IR1000Aand125Vdc-IR400A(IR1000Aat75Vdc)

ELECTRICAL CHARACTERISTICS

% of Amp Rating

Opening Time

100%

4 Hours Minimum

135%

60 Minutes maximum

200%

120 Seconds Maximum
