Technical Data 2119

Effective June 2017

Supersedes July 2009

Product features

HTB

1/4” x 1 1/4” and 5 mm x 20 mm Panel-mount

fuse holders

•

For 1⁄4" x 1 1⁄4" and 5 mm x 20 mm fuses

•

All holder bodies have the option of using

1⁄4" x 1 1⁄4" or 5 mm x 20 mm carriers

•

Withstands 15 to 20 Lb-In torque to mounting

nut when mounting fuse holder to panel

•

High temperature, flame retardant,

Thermoplastic meets UL 94V0

Agency information

•

UL Recognized: IZLT2, E14853

•

CSA Component Acceptance: Class 6225-01, File 47235

•

VDE Certified: 136128, HTB-XXM

•

SEMKO Certification: Ref. #0146149/01, HTB-XXM

•

CE

Mounting Dimensions - in (mm)

Maximum Panel Thickness

Body Type

Inch

mm

HTB-2

0.30

7.62

HTB-3

0.30

7.62

HTB-4

0.125

3.18

HTB-5

0.125

3.18

HTB-6

0.30

7.62

HTB-8

0.125

3.18

HTB-9

0.125

3.18

Specifications

Product

UL Rating

CSA Rating

Voltage

Fuse

Quick

Code

(amps)

Rating

Size

Connect

HTB-X2I

20

16

250

1

⁄4" x 1 1⁄4"

3

⁄16"

HTB-X4I

20

16

250

1

⁄4" x 1 1⁄4"

3

⁄16"

HTB-X6I

20

16

250

1

⁄4" x 1 1⁄4"

1

⁄4"

HTB-X8I

20

16

250

1

⁄4" x 1 1⁄4"

1

⁄4"

HTB-X2M

16

250

5 x 20mm

3

⁄16"

HTB-X4M

16

250

5 x 20mm

3

⁄16"

HTB-X6M

16

250

5 x 20mm

1

⁄4"

HTB-X8M

16

250

5 x 20mm

1

⁄4"

Ordering Information

FUSE CARRIER ONLY

HTB-

S

P

Packing

Product

Fuse Carrier

Splash Proof

(Blank) – Std.

Symbol

I — 1/4˝ x1 1/4˝

Cap with O-Ring

[IP53 rating]

BK/ – Bulk

M — 5 x 20mm

(Optional on Knob

Packaging

Product

Fuse Carrier

Holders Only)

(Blank) – Std.

Symbol

I — 1

/4

˝x 11/4˝

Body Conguration and Mounting

Knob Holders

2 — Low Prole (Rear Panel Hex-Nut)

4 — High Prole

Rear Terminal Conguration

BK/ – Bulk

FT — Knob Type

M — 5mm x 20mm

2 — Solder / 3/16˝ Quick-Connect

(For 20, 40, 60,

-R

(In-Line)

and 80 Series

4 — Solder / 3/16˝ Quick-Connect

Only)

*6 — (Front Panel Hex-Nut)

(Right Angle)

ST — Screwdriver

8 — Low Prole (Snap-In)

Screwdriver Slotted Holders

3 — Low Prole

5 — High Prole

9 — Low Prole (Snap-In)

6 — 1/4˝ Quick-Connect (In-Line)

RoHS

Slotted (For 30,

Compliant

8 — 1/4˝ Quick-Connect (Right Angle)

50, and 90 Series

Only)

*Prole varies with panel thickness. Holder installs thru rear of panel.

Replacement Parts

Packaging

Packaging Code

x

Description

Blank

10 fuse holders packed into a carton

BK

100 fuse holders packed into a cardboard shelf package
