FRS-R-61/4 数据表(PDF) 3 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
FRS-R-61/4 数据表(HTML) 3 Page - Eaton All Rights Reserved. |
|
|
3 / 4 page  3 Technical Data 1017 Effective August 2018 Fusetron™ 600 V Class RK5 FRS-R — 600 Vac/300 Vdc, 1/10-60 A, dual element, time-delay fuses Eaton.com/bussmannseries Time-current curves - average melt 10 to 60 amps AMP RATING CURRENT IN AMPS Current-limitation curves Current-limiting effects Prosp. S.C.C. Let-through current (apparent RMS symmetrical vs. fuse rating) — 30 A 60 A 5000 1000 1000 10,000 1000 2000 15,000 1000 2000 20,000 2000 2000 25,000 2000 2000 30,000 2000 3000 35,000 2000 3000 40,000 2000 3000 50,000 2000 3000 60,000 2000 3000 70,000 3000 4000 80,000 3000 4000 90,000 3000 4000 100,000 3000 4000 150,000 3000 5000 200,000 4000 6000 400000 9000 8000 7000 6000 300000 200000 100000 5000 4000 90000 3000 2000 1000 80000 70000 60000 B A 50000 40000 30000 20000 10000 30A 60A RMS SYMMETRICAL CURRENT IN AMPS A-B = ASYMMETRICAL AVAILABLE PEAK (2.3 X SYM RMS AMPS) |
|
|
