Key Features

l SMT Technology

l Miniture Package

l I / O isolation 1000VDC

l Efficiency Up To 83%

l MTBF > 2,000,000 Hours

l Low Cost

Mechanical Configuration

0.77 (19.5)

0.02

(0.5)

0.02

(0.5)

0.10

(2.54)

0.09

(2.3)

0.40

(10.2)

0.126

(3.2)

0.01

(0.25)

0.05

(1.25)

0.30

(7.6)

1

2

4

5

6

All dimensions typical in inches (mm). Tolerance= +/- 0.01 (+/- 0.25)

+Vo

Bipolar

Push-Pull

Inverter

+Vin

-Vin

Com.

-Vo

LC

Filter

+Vo

Bipolar

Push-Pull

Inverter

+Vin

-Vin

-Vo

LC

Filter

+Output

6

Common

No Pin

5

-Output

4

-Input

2

+Input

1

Dual Output

Single Output

Pin Connections

2.7g

Weight

Non-Conductive Black Plastic

Case Material

19.5*7.6*10.2 mm

0.77*0.30*0.40 inches

Case Size

Physical Characteristics

TOTAL POWER INT'L

MAU300 Series 2 Watt Ultra Miniature High Isolation SIP DC/DC

Converters with

Single & Dual Output

TOTAL POWER INT'L Tel: 877-646-0900 Fax: 978-453-7395

Email: sales@total-power.com http://www.total-power.com

-1-
