Cree 4-mm Oval LED

C4SMA-RGY/GGY/BGY

ORDER CODE TABLE*

C4SMA-BGY

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Pack-

age

Min.

Max.

Color Bin

Min.

(nm)

Color Bin

Max.

(nm)

Blue

C4SMA-BGY-CR2T3451

605

1415

B4

465

B5

475

Bulk

Blue

C4SMA-BGY-CR34Q4S1

Any 4 consecutive sub-bins: R3(660) - S4(1100)

Any 1 color bin from B4 (465) to B5 (475)

Bulk

Blue

C4SMA-BGY-CR44Q4S1

Any 4 consecutive sub-bins: R4(715) - T1(1205)

Any 1 color bin from B4 (465) to B5 (475)

Bulk

Blue

C4SMA-BGY-CR2T3452

605

1415

B4

465

B5

475

Ammo

Blue

C4SMA-BGY-CR34Q4S2

Any 4 consecutive sub-bins: R3(660) - S4(1100)

Any 1 color bin from B4 (465) to B5 (475)

Ammo

Blue

C4SMA-BGY-CR44Q4S2

Any 4 consecutive sub-bins: R4(715) - T1(1205)

Any 1 color bin from B4 (465) to B5 (475)

Ammo

Notes:

1. The above kit numbers represent order codes that include multiple intensity-bin and color-bin codes. Only one

intensity-sub-bin code and one color-bin code will be shipped on each reel. Selected single intensity-bin, single

color-bin codes will be orderable in certain quantities. For example, any four consecutive sub-bins from V1 to W2

mean only one intensity bin with four sub-bins of the following brightness ranges (V1-V4, V2-W1, V3-W2) will be

shipped by Cree. For example, any one-color bin from G7 to Ga means only one color bin (G7 or G23 or G8 or G45

or G9 or G67 or Ga) will be shipped by Cree.

product safely.

#1: Refer to http://www.cree.com/led-components/media/documents/LED_Lamp_Reliability_Test_Standard.pdf

#2: Refer to http://www.cree.com/led-components/media/documents/sh-HB.pdf
