PRODUCT FAMILY DATA SHEET

C503T-RAS/RAN

C503T-RCS/RCN/ACS

Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice.

Cree, the Cree logo and XLamp are registered trademarks of Cree, Inc.

PRODUCT DESCRIPTION

Round LEDs offer superior light out-

put for excellent readability in sun-

light and dependable performance.

They provide extremely stable light

output over long periods of time.

These lamps are made with an ad-

vanced optical-grade epoxy offering

superior high-temperature and high-

moisture-resistance performance in

outdoor signal and sign applications.

FEATURES

• Size (mm): 5

• Color and Typical Dominant

Wavelength:

Red (628nm)

Amber(591nm)

• Luminous Intensity (mcd)

C503T-RAS/RAN:

(4180 - 16800)

C503T-RCS/RCN:

(2130 - 8200)

C503T-ACS:

(2130 - 8200)

• Viewing angle:

C503T-RAS/RAN:

15 degree

C503T-RCS/RCN/ACS:

30 degree

• Lead - Free

• RoHS Compliant

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

www.cree.com/xlamp

Copyright © 2011 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and

the Cree logo are registered trademarks of Cree, Inc.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

APPLICATIONS

• Electronic Signs & Signals

(ESS)

• Motorway Signs

• Variable Message Sign (VMS)

• Advertising signs

• Petrol Signs

• Amusement
