TECHNICAL DATA SHEET

ATE-R10

<FOR TOPLITE COB MODULE>

3 / 9

A/1

ATE-R10 SERIES

Revision issued in 2014.

3-2. ELECTRICAL-OPTICAL CHARACTERISTICS

**

PARAMETER

SYMBOL

CONDITION

MIN.

TYP.

MAX.

UNIT

common

33.6

36

39.6

V

Beam Angle

Deg

—

120

—

Deg

W

**

Color Temp.

2870

3045

3220

K

**

Ra

80

—

—

—

Φ

590

615

—

lm

Luminous Efficiency

η

91

95

—

lm/W

Φ

622

648

—

lm

Luminous Efficiency

η

96

100

—

lm/W

D

**

Color Temp.

4745

5028

5311

K

**

Ra

80

—

—

—

Φ

648

680

—

lm

Luminous Efficiency

η

100

105

—

lm/W

Φ

687

712

—

lm

Luminous Efficiency

η

106

110

—

lm/W

C

**

Color Temp.

6020

6530

7040

K

**

Ra

80

—

—

—

Φ

680

712

—

lm

Luminous Efficiency

η

105

110

—

lm/W

Φ

720

745

—

lm

Luminous Efficiency

η

101

115

—

lm/W

(Note) Parameters is formulated based on shipping samples

*1. After 20 ms drive, Measurement tolerance: ± 3 %

*2. Monitored by Toplight's 1 m integrating sphere, after 20 ms drive, Measurement tolerance: ± 10 %
