TECHNICAL DATA SHEET

ATE-R20-12W

<FOR TOPLITE COB MODULE>

3 / 9

A/1

ATE-R20-12W

SERIES

Revision issued in 2014.

3-2. ELECTRICAL-OPTICAL CHARACTERISTICS

**

PARAMETER

SYMBOL

CONDITION

MIN.

TYP.

MAX.

UNIT

common

34.8

36.6

39.6

V

Beam Angle

—

—

120

—

Deg

W

**

Color Temp.

—

2870

3045

3220

K

**

Ra

80

—

—

—

Φ

1056

1116

—

lm

Luminous Efficiency

η

88

93

—

lm/W

Φ

1140

1200

—

lm

Luminous Efficiency

η

95

100

—

lm/W

D

**

Color Temp.

—

4745

5028

5311

K

**

Ra

80

—

—

—

Φ

1200

1260

—

lm

Luminous Efficiency

η

100

105

—

lm/W

Φ

1296

1344

—

lm

Luminous Efficiency

η

108

112

—

lm/W

C

**

Color Temp.

—

6020

6530

7040

K

**

Ra

80

—

—

—

Φ

1344

1392

—

lm

Luminous Efficiency

η

112

116

—

lm/W

Φ

1420

1480

—

lm

Luminous Efficiency

η

118

122

—

lm/W

(Note) Parameters is formulated based on shipping samples

*1. After 20 ms drive, Measurement tolerance: ± 3 %

*2. Monitored by TOPLITE's 1m integrating sphere, after 20 ms drive, Measurement tolerance: ± 10 %

*3. Monitored by TOPLITE's 1m integrating sphere, after 20 ms drive, Measurement tolerance:± 2
